Embark on a liberating sonic adventure with UNO Synth PRO X, a powerful analog synthesizer that’ll ignite your creativity and elevate your music to new dimensions. Prepare to be inspired as you explore a world of infinite possibilities, where technology meets the timeless allure of analog warmth.
Listen to audio demos
Adjust the master volume, the drive and glide amount and select the voice mode of your sound.
Here you can adjust all the parameters of the 3 analog oscillators.
Play and sculpt your sound with the 2 analog filters.
Filter 1 is the LP/HP OTA-based.
Filter 2 is the 2/4 Pole LP SSI-based.
Adjust the parameters for the 3 slots of effects available:
Modulations (M), Delay (D) and Reverb (R).
ENVELOPES AND LFOs:
Design your sound with the 3 ADSR envelopes and modulate with the 2 LFOs.
Note: in Bassline Mode, Sustain and Release are replaced with ACC Decay and ACC amount.
Use those buttons to manage presets, settings and activate the Bassline Mode or the arpeggiator.
SHIFT is the button to activate the second functions of some parameters.
Note: Unit powers ON/OFF automatially when connecting the power supply.
If you wish, you can hold the HOLD button to power ON/OFF the unit.
Push and turn the encoder to acces the edit menus shown on the display or to fine tune parameters.
Use the BACK button to exit any menu.
Play your sound and register notes on the sequencer.
Press + or - to shift the keyboard octave.
You can even select the scale on the relative setup menu.
SEQUENCER STEPS and PAGES:
Use the steps to visualize and edit your sequence, and add/remove steps using the pages.
You will use those buttons for other multiple selections, so go further in the manual to discover the full potential.
Spice up and manage your sequence with accidents and useful tools.
RECORD AND PLAY BUTTONS:
Start/stop and record your sequence at any moment.
Unit requires 5V 1.5A.
Please use only the included charger in the box (PSU-3A).
Connect the included USB-C cable for MIDI and Power.
We recommend using the included Power Supply instead of USB whenever possible given the minimum requirement of 5V - 1.5A.
ASSIGNABLE CV/GATE IN/OUT JACKS:
Use the Matrix to route the synth’s sources and destinations to these programmable CV and GATE jacks to interface with external modular equipment.
Route mono audio in to filters and FXs or clean pass-thru.
BALANCED 1/4" STEREO OUTPUTS:
For best results, use TRS balanced cables. You may also use TS unbalanced cables.
Connect external MIDI gear using standard 5-pin DIN cables.
Featuring three discrete wave-morphing oscillators, the UNO Synth PRO X invites you to explore a vast sonic landscape. Unleash your imagination with PWM, sync, FM, and ring modulation capabilities: Your sonic palette knows no bounds.
Discover a new realm of sonic possibilities with the UNO Synth PRO X's dual-filter design, combining classic OTA and SSI-chip-based filters. Immerse yourself in the moment as you weave intricate textures and shape your sound to perfection. Dive deeper into sonic exploration with the 16-slot modulation matrix enabling you to create intricate and evolving textures.
Take complete control over your music with over 30 hands-on controls, providing immediate access to your sound-shaping tools. With USB, MIDI, CV and Gate in/out options, integrating the UNO Synth PRO X into your setup is effortless.
With 10 studio-quality FX in three slots and an analog drive, your music will further come to life with warmth and character.
Unleash your creative potential, easily creating complex ever-evolving sequences. Try the 10-mode arpeggiator, equipped with a pattern designer to bring your melodies to life. New horizons are just around the corner with the Bassline mode, along with legato, mono and paraphonic modes, offering unprecedented expression of your musical ideas.
With 256 user-editable presets the UNO Synth PRO X is a playground for sonic fun and exploration. Effortlessly sculpt save and recall your own custom sounds recapturing every moment of your creativity. And with the included Editor/Librarian software providing seamless control from your Mac or PC anything becomes possible. The Editor works as both a standalone application and as a plug-in inside your favorite DAW. This means you can program and play the UNO Synth PRO X just like a virtual instrument.
UNO Synth PRO X
UNO Synth PRO X - Matrix
UNO Synth PRO X - Effects
UNO Synth PRO X - Librarian
UNO Synth PRO X - Settings
The UNO Synth PRO X is not only a fun sound-design partner but also the perfect musical companion on the go, adapting to any environment. From backpack to mainstage, new sonic destinations will always be within reach.
To protect your UNO Synth PRO X when you’re carrying it around, you can order the UNO Synth PRO X Travel Bag, durable 100% polyester cases featuring a stitched-in UNO Synth logo, adjustable straps and a zippered pouch for cables and other small items.
UNO Synth PRO X Travel Bag
Whether you're a seasoned sound designer or on the way to becoming one, UNO Synth PRO X is here to travel physically and sonically wherever you go.
